Port

Alarm Output

1 × alarm output, NC/NO, 60 VDC, Max. 400 mA
1 × tamper output, NC, 28 VDC, Max. 100 mA

Function

Indicator Light

Red indicator

Technical

Sensor

Dual-element low-noise pyroelectric infrared sensor

Detection Mode

Passive Infrared Detection (PIR)

Sensitivity

Adjustable sensitivity

Detection Range

Distance: Φ7 m (22.97 ft) when installed 2.5 m (8.20 ft) above the floor, Φ12 m (39.37 ft) when installed 3.6 m (11.81 ft) above the floor and Φ13 m (42.65 ft) when installed 4.5 m (14.76 ft) above the floor
Angle: 360°

Detection Speed

0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s)

White Light Resistance Level

6,500 lux

Two-way Digital Temperature Compensation

Yes

Pulse Count

1P; 2P

Operating Current

≤30 mA (12 VDC)

Alarm Current

≤10 mA

General

Power Supply

9–18 VDC

Power Consumption

0.54 W (Max.)

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

≤95% (RH)

Product Dimensions

33.0 mm × Φ115.0 mm (1.30" × Φ4.53")

Net Weight

96.3 g (0.21 lb)

Gross Weight

133.3 g (0.29 lb)

Installation

Ceiling mount at a height of 2.5 m–4.5 m (8.20 ft–14.76 ft)

Casing Material

ABS and PE

Appearance Color

White

Protection

CE

Certifications

CE

Anti-corrosion Level

Basic Protection

Storage Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Storage Humidity

≤95% (RH)

Packaging Dimensions

50.0 mm × 142.0 mm × 140.0 mm (1.97" × 5.59 × 5.51") (L × W × H)
