Video

Video Codec

H.265, H.264 HP, H.264 BP, H.263, H.263+

Video Resolution

Main Stream, 1080P, 720P, 4CIF, CIF
Demo Stream, 1080P, UXGA, WXGA, SXGA, XGA, SVGA, VGA

Frame Rate

25fps, 30fps, 50fps, 60fps

Video Bitrate

64Kbps~10Mbps

Dual Stream

Dual 1080P@60fps

Audio

Audio Codec

OPUS, G711a, G711u, G722, MP3 G722_1c, AAC_LC, G719, G722.1, G728, G729

Audio Sample Rate

8KHz–48KHz

Audio Bitrate

8Kbps ~ 256Kbps

Audio Processing

AEC (Acoustic Echo Cancellation) , AGC (Automatic Gain Control) , ANS (Automatic Noise Suppression), Self-Adaptive Post-filtering, Audio Error Correction and Lip Sync

Communicaton

Communicaton Protocols

ITU-T H.323, IETF SIP

Dual Stream Protocols

H.239, BFCP

Transmission Protocols

IPv6/IPv4, TCP/IP, FTP/FTPS, RTP, RTCP, HTTP/HTTPS, SNMP, SSH, DNS, NTP, PPPoE, DHCP, SRTP, TLS

Other Protocols

H.221, H.225, H.235, H241, H.245, H.281, H.460

Network

Network Packet

LossTolerance

In the event of a 30% packet loss, the conference audio and video is unaffected

Network Delay Tolerance

Normal conference processing for up to 800ms delay

Other Features

Audio priority/Packet retransmission/Intelligent speed control/error correction

Security

Physical environment

Adopts reliable designs (environment/safety/EMC/thermal) to ensures the system runs stably for a long time

Network transmission

Support H.235/SRTP/TLS/AES 128/AES 256 encryptions, etc. Support conference access password/SSH/HTTP/WEB administrator password

Video Interfaces

Video Inputs

2 × HDMI, 1 × 3G–SDI, 1×CVBS, 1 × HDCVI, 1 × HDMI/DVI/VGA/YPbPr

Video Outputs

2 × HDMI, 1 × 3G–SDI, 1 × HDCVI, 1 × HDMI/DVI/VGA/CVBS/S–Video

Audio Interfaces

Audio Inputs

2 × XLR, 2 × RCA, 1 × 6.35mm, 1 × DH–AI, 1 × HDMI

Audio Outputs

4×RCA, 1 × 6.35mm, 1×HDMI

Network Interfaces

Network

2 × RJ45 10/100/1000M self–adaptive network port

Other Interface

USB

1 × USB port

Control

2 × RS232/RS485

Remote control

Support IR remote control

Physical Features

Power Supply

12V DC

Power Consumption

≤60W

Operating Conditions

Temperature: 0°C~45°C (+10°F~+113°F)
Humidity: 10%~80% (working) 0%~95% (storage)

Dimensions (W × D × H)

435mm × 280mm × 66mm

Package Size (W × D × H)

573mm × 407mm × 173mm

Weight

Net Weight: 4.5kg (9.9lb)
Gorss Weight: 6kg (13.2lb)
