Smoke Detector

Indicators

Standby: Green indicator flashes once per minute
Fault: Red indicator flashes once per minute
Alarm: Red indicator flashes once per second
Self-testing: Red indicator flashes once per second

Protection Area

30 m2–60 m2

Working Principle

Photoelectric

Alarm Mode

Sound and LED Indicator

Operating Voltage

12V DC/PoE and 3V lithium battery

Operating Current

≤ 30uA (Camera excluded)

≤ 300mA (Camera included)

Battery Life

＞ 3 years

Alarm Type

Smoke alarm, fault alarm, low battery alarm, heat alarm, humidity alarm

Alarm Volume

≥ 85 dB (A) @ 3 m (9.84 ft)

Camera

Appearance

Circular

Image Sensor

1/2.7" CMOS

Pixel

5 MP

Max. Resolution

2592 (H) × 1944 (V)

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3s~1/100000s

Min. Illumination

0.002Lux (color)
0.0002Lux (dark)
0Lux (IR)

S/N Ratio

＞ 56 dB

Illumination Distance

Distance up to 20 m (65.62 ft)

Illuminator Number

2 (IR LED)

Lens

Lens Type

Fixed-focal

Lens Mount

M8

Focal Length

2.0 mm

Max. Aperture

F2.0

Field of View

Horizontal: 144°; Vertical: 92°; Diagonal: 179.6°

Iris Control

Fixed

Close Focus Distance

0.2 m (0.66 ft)

Smart Event

AI Event

Flame detection

Video

Video Compression

H.265; H.264; H.264H; H.264B

Smart Codec

Smart H.265+/ Smart H.264+

Video Frame Rate

Main stream:
2592×1944 (1 fps-20 fps)
2688×1520 (1 fps–25/30 fps)
2560×1440 (1 fps–25/30 fps)
2304×1296 (1 fps–25/30 fps)
1920×1080 (1 fps–25/30 fps)
Sub stream:
D1 (1 fps–20 fps)
D1 (1 fps–25/30 fps)
Third stream:
1920×1080 (1 fps-17/24 fps)

Video Bit Rate

H.264: 32 Kbps–10240 Kbps
H.265: 12 Kbps–7168 Kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

90 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D NR

Default Bit Rate with Default Resolution

2048 Kbps (2688 × 1520)

Image Rotation

Yes

Image Flip

Yes

Mirror

Yes

Rotation

Yes

Privacy Masking

8 areas

Language

English, TradChinese, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Turkish, Polish, Romanian, Hungarian, Korean, Czech, Dutch, Ukrainian, Vietnamese, Arabic, Spanish(Europe), Hebrew, Thai, Bahasa Indonesia

Audio

Audio Port

Yes

Built-in MIC

Yes

Built-in Speaker

Yes

Audio Compression

PCM; G.711a; G.711Mu; G.726; AAC; G.723

Audio Sampling

8KHz/16KHz/32KHz/48KHz/64KHz

Alarm

Alarm

Yes

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; scene changing; audio detection; flame detection;heat detection; humidity detection; smoke detected alarm; fault alarm; smoke alarm disconnected; low battery alarm

Network

Network Port

1 RJ-45 PoE 10M/100M Ethernet ports

Network Protocol

HTTP;TCP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;IPv4/v6;SNMP;QoS;UPnP;NTP

Interoperability

ONVIF; MileStone; Genetec; CGI; PISA

User/Host

10 channels at most

Storage

FTP; SFTP; Micro SD card (256G); NAS

Browser

IE7 and newer versions; Chrome 8+; Firefox 3.5+; Safari 5+

Function

Image Setting

Brightness; Contrast; Sharpness; Saturation; gamma

OSD Overlay

Channel title / time title / geographical location / battery voltage / heat / humidity

Record Mode

Manual record; video detection record; schedule record; alarm record Record priority: Manual > external alarm > video detection > schedule

Micro SD Card (Max.)

256 GB

Default

Support one-click restore

User Management

Up to 20

Security

Username and password; MAC address; HTTPS; IEEE802.1x; network access control

Certification

Certification

CE-CRP: EN 14604:2005/AC:2008

CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility
Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B

Port

Audio Input

1 channel (RCA port)

Audio Output

1 channel (RCA port)

Alarm Input

2 channels In: 5mA 3V–5V DC

Alarm Output

2 channels Out: 300mA 12V DC

RS-485 Port

1 (baud rate range:1200 bps–115200 bps)

Power

Operating Voltage

Adapter: 12V DC(±25%); PoE: 802.3af

Power Supply

DC12V+PoE

Power Consumption

Basic power consumption: 2.1W (12V DC); 2W (PoE)
Max. power consumption (ICR + IR LED intensity): 4.9W (12V DC); 4.8W (PoE)

Environment

Operating Temperature

–10°C to +55°C (+14°F to +131°F)

Operating Humidity

0%–95% RH (non-condensing)

Structure

Casing Material

Plastic

Product Dimensions

175.3 mm×120.0 mm×81.6 mm(6.9" × 4.72" × 3.21")

Packaging Dimensions

205 mm × 148 mm × 111 mm (8.06" × 5.82" × 4.37")(L × W × H)

Installation

Ceiling mount

Power Adapter

Optional

Lens

Standard
