System

Main Processor

Embedded Processor

Network Protocol

UDP;TCP;IPv6;IPv4;RTSP;SIP;P2P;RTP

OSDP Protocol

Yes

SDK and API

Yes

Basic

Product Type

Standalone

Display Screen

8" LCD

Screen Type

Capacitive Touchscreen

Screen Resolution

1280 (V) × 800 (H)

Camera

1/2.7" 2MP CMOS HD camera with WDR

WDR

120 dB

Light Compensation

Auto IR

Voice Prompt

Yes

Speaker

Yes

Casing Material

PC

Function

Verification Method

Card, password, face, fingerprint, QR code and remote

Unlock Mode

Unlock through card, password, face, fingerprint, QR code and remote unlock. You can also combine them to create your own personal unlock methods.

Card Type

IC card

Frequency Range

13.560 MHz

Period List

128

Holiday Period

128

Network Update

Yes

First User Unlock

Yes

Remote Verification

Yes

Restricted List/Trusted List

Yes

Wi-Fi

Yes

Wireless Standard

IEEE802.11b/802.11g/802.11n

Wireless Frequency Range

2.4 GHz

Max Transmission Power

≤20 dBm@2400-2483.5 MHz

Wireless Security Encryption

WPA/WPA2;WPA-PSK/WPA2-PSK

Advertisement Playing

Support graphic advertisement play

Peripheral Card Reader

1 × RS-485 card reader, and 1 × Wiegand card reader

Multi-user Authentication

Yes

Real-time Monitoring

Yes

Multi-factor Authentication

Yes

Capture Function

Yes

Web Configuration

Yes

Auto Registration

Yes

Performance

IC Card Encryption

Yes

Card Reading Distance

4 cm–6 cm (1.57"–2.36")

Face Recognition Height Range

0.9 m–2.4 m (2.95 ft–7.87 ft)

Face Recognition Distance

0.3 m–3 m (0.98 ft–9.84 ft)

Face Recognition Accuracy

99.9%

Face Recognition Time

0.2 s

User

User (Card) Type

Normal, VIP, patrol, guest, customized user 1, customized user 2 and more

Capacity

User Capacity

100000

Face Image Capacity

100000

Fingerprint Capacity

10000

Card Capacity

500000

Password Capacity

100000

Record Capacity

300,000 unlock records

Port

RS-485

1

RS-232

1

Wiegand

1, input and output port

USB

1 × USB 2.0 port

Network Port

1 × 10 Mbps/100 Mbps Ethernet port

Alarm Input

2 (On/off signal)

Alarm Output

2 (Relay)

Alarm Linkage

Yes

Exit Button

1

Door Status Detection

1

Lock Control

1

Alarm

Anti-pass Back

Yes

Tamper Alarm

Yes

Duress Alarm

Yes

Door Sensor Timeout

Yes

Intrusion

Yes

Illegal Card Exceeding Threshold

Yes

Duress Fingerprint

Yes

General

Power Adapter

Included

Power Supply

12 VDC, 2 A

Protection

IP65

Power Consumption

≤24 W

Product Dimensions

237.4 mm × 122.6 mm × 24.8 mm (9.35" × 4.83" × 0.98")

Packaging Dimensions

390.0 mm × 320.0 mm × 360.0 mm (15.35" × 12.60" × 14.17") (H × W × D)

Transport Package Dimensions

299.0 mm × 164.0 mm × 72.0 mm (11.77" × 6.46" × 2.83") (H × W × D)

Operating Temperature

–30 °C to +60 °C (–22 °F to +140 °F)

Operating Humidity

0%–90% (RH), non-condensing

Operating Altitude

0 m–1,300 m (0 ft–4265.09 ft)

Operating Environment

Indoor; outdoor

Gross Weight

1.0 kg (2.20 lb)

Accessory

Included wall mount bracket

Installation

Turnstile Mount;86 case mount;Wall;Floor Bracket Mount
