LPH98-MC470-P-S2

MOQ: 1 Pieces

Delivery time: 15 Day

> Built-in DeepHub Meeting software for cloud base online conference and with real-time collaboration function. > (The Meeting software installed on the device includes a one-year usage license, after which a renewal fee will be required for continued use.) > Displays in 4K Ultra HD and uses 4K UI. > With its 2 built-in mid-high frequency speakers, and 1 low-frequency speaker, the device supports 2.1-channel audio output. The total power is 60 W.

> Produces vibrant visuals through its high color coverage (90% NTSC High Gamut Screen) and accurate color reproduction (ΔE≤1.5). > Features split screen, and performs screen sharing between the whiteboard and phones, computers, tablets and more devices. > Microsoft Office and other related software can be installed, and it can play audio and video files in various formats. > Offers a smooth writing experience through handwriting recognition, pen writing, the fast writing response speed, and pen pressure recognition for a real writing experience.

> Support AI recognition of text and drawings. > Intelligent pen detection that automatically wakes up the whiteboard for annotations when the pen is lifted. > Built-in AI 52M camera and 16 array microphone that produces excellent quality visual and audio communication. Supports auto-framing and voice tracking. > Features sound source positioning. > NFC and Fingerprint unlock for protection of user information. > Includes a full-featured Type-C IN port and supports charging through USB PD up to 65 W.

Product Details

Built-in System

Operating System

Android 14

CPU

Quad-core A73 + Quad-core A53

CPU Frequency

2.2 GHz + 2.0 GHz

GPU

ARM Mali-G52 MP8 (8EE)

RAM

20 GB (System: 16 GB, Camera: 4 GB）

ROM

128 GB

NFC

Supports quick unlock via NFC

Function

Operating System of External Module

Windows 7/8/10

Wi-Fi Hotspot

Dual-band 2.4 G/5 G; supports enabling Hotspot and Wi-Fi at the same time

LCD Panel

Screen Size

98 inch

Backlight

DLED

Aspect Ratio

16:9

Brightness

450 cd/m² (typ.)

Resolution

3840 (H) × 2160 (V)

Viewing Angle

H (178°) / V (178°)

Lifespan

≥50, 000 hr

Display Color

90% NTSC (typ.)

Refresh Rate

60 Hz

Static Contrast Ratio

1200 (typ.)

Response Time

8 ms (typ.)

Camera

Android: Photo: 52 MP; Video: 8 MP
Windows: Photo: 8 MP; Video: 8 MP

Auto Control

Auto flip; Auto white balance

Distortion

–8.6%

Max. Resolution

Photo: 9632 (H) × 5418 (V); Video: 3840 (H) × 2160 (V)

Storage

8GB eMMC

Field of View

H: 87°; V: 49°; D: 99°

Face Detection

Yes

Digital Zoom

Yes, supports up to 9x digital zoom.

Device Ports

Light Sensor

Front Button

1 × power button (right side)

Front Ports

1 × USB 3.2 Gen1 (left side)

Network Port

1 × RJ-45

Wi-Fi

Yes, 1 × Station, 1 × AP

Wi-Fi Standard

Station: 802.11b/g/n/a/ac
AP: 802.11b/g/n/a/ac/ax

Wi-Fi Frequency Range

2400–2483.5 MHz, 5150–5350 MHz, 5470–5725 MHz, 5725–5850 MHz

MAX Power Transmission (Wi-Fi)

≤20 dBm@2400–2483.5 MHz; ≤23 dBm@5150–5250 MHz;
≤20 dBm@5250–5350 MHz; ≤27 dBm@5470–5725 MHz;
≤14 dBm@5725–5850 MHz

Bluetooth

Yes

Bluetooth Standard

BR/EDR/BLE, BT5.3

Bluetooth Frequency Range

2400–2483.5 MHz

MAX Power Transmission (Bluetooth)

≤20 dBm@2400–2483.5 MHz

RFID Modulation Method

ASK

RFID Frequency Range

13.56 MHz

MAX Power Transmission (RFID)

42dBuA/m @10 m

USB

3 × USB 3.2 Gen1 Type-A; 1 × Micro USB 2.0

RS-232

1 × DB9 port, male connector

Video Input

2 × HDMI 2.0 (4K@60 Hz）

Video Output

1× HDMI 2.0 (4K@60 Hz）

Audio Output

1 × 3.5 mm Line Out port; 1 × SPDIF port

Others

1 × Touch port

IrDA

Microphone

16 arrays

Type-C Port

1 × Type-C IN (DP IN (4K60 fps) + USB 3.2 Gen1 HOST+ USB 2.0 Device (touch) + PD 65 W)

Touchscreen

Response Time

≤4 ms

Touch Technology

Infrared

Touch Points

32@Android, 50@windows

Valid Touch

1.5 mm (0.06") (over 90% touch area）

Writing Mode

Finger + Pen (attaches magnetically)

Anti-light Interference

Anti-dazzle tempered glass

Surface Hardness

≥9H

Touch Resolution

32767 × 32767

Number of Multi-user Writing Points

10 points (over 90% touch area）

Speaker

Number of Cavities

Frequency

150 Hz–20 kHz

Power

2.1 channel, front-end 2 × 20 W + rear-end 20 W

Built-in Speaker

Fingerprint

Fingerprint Capacity

100

Fingerprint Resolution

160 × 160

FAR

<0.001%

Microphone

Pick-up Distance

Far-field sound pickup: 8 m–12 m (26.25 ft–39.37 ft)

Number of Microphones

16 arrays

AGC

Yes

Echo Cancellation

Yes

Polar Pattern

Omnidirectional

Intelligent Noise Filtering

YES

General

Power Supply

100–240 VAC, 50/60 Hz

Power Consumption

555 W (basic), 600 W (max)

Operating Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Storage Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

10%–90% (RH), non-condensing

Storage Humidity

10%–90% (RH), non-condensing

Product Material

Metal casing

Protective Glass

3.2 mm Anti-dazzle tempered glass

Casing Color (Frame/Rear)

Black on the left and right, Starry Gray on the top and bottom.

Product Dimensions

2,218.3 mm × 110.2 mm × 1,383.6 mm (87.20" × 4.34" × 54.49") (L × W × H)

Frame Size

Top border: 28.6 mm (1.13"), left and right borders: 17.9 mm (0.70"), bottom border: 69.6 mm (2.74")

Packaging Dimensions

2,339 mm × 257 mm × 1,480 mm (92.09" × 10.12" × 58.27") (L × W × H)

Net Weight

102 kg (224.87 lb)

Gross Weight

127.8 kg (281.41 lb)

Holes Distance

1,000 mm × 400 mm (39.37" × 15.75")

Installation

Wall mount; mobile bracket

Standby Power Consumption

≤0.5 W

Packing List

1 × Smart interactive whiteboard
1 × Power cord
2 × Stylus pen
1 × Quick start guide
1 × Wall mount bracket
1 × Remote control
1 × Legal and Regulatory Information
1 × Wall-mount screw pack

Glass Thickness

3.2 mm (0.13")
